MC-D06 LDR Beds (Low Position)

share

The MC-D06  Low Position Obstetric Table is designed for patients in maternity - gynaecology wards, and in all stages of childbirth: antenatal period, childbirth, postpartum period



Product Details

Features:

The MC-D06 Low Position Obstetric Table is designed for patients in maternity - gynaecology wards, and in all stages of childbirth: antenatal period, childbirth, postpartum period

Bed is constructed of steel profiles covered with powder varnish

Height adjustment of the bed frame realized due to hydraulic pump regulated by foot pedal

Back segment inclination angle regulated by gas spring

Trendelenburg and Reverse-Trendelenburg positions are realized by gas springs with interlocking

Leg segment can be pulled under the seat segment

Removable ABS covers of the seat segment and protractile frame ensure keeping the bed clean

Wall fenders mounted on the bed corners in the head part of the bed

Side rails are fixed to the back segment and lifted up enhance safety of the patient (patient with newborn) and make it possible to change the position of the body. After releasing the locker, the rails can be folded down


pecifications:

Bed’s length82" (2050 mm)
Bed’s length in chair position42" (1050 mm)
Maximum width39.2" (980 mm)
Bed frame width34.8” (870mm)
Height adjustment580mm-885mm (hydraulic pump)
Back rest inclination angle70° (gas spring)
Trendelenburg position12° (gas spring)
Reverse Trendelenburg position5° (gas spring)
Permissible load160kgs
Leg section telescopic distance550mm
Gynaecological bowl capacity14L
