Main features
- Bed Frame Electrophoresis and powder coating
- Bed platform MS perforated platform with ventilation hole, molded
- Motor Quiet and robust electric actuators provide reliable operation
- Hand remote controller of all electrically operated functions and movements
- Handrails Collapsible aluminum railing with 6 bars
- Head and Footboard ABS material, detachable
- Castors: Caster diameter of 125mm with diagonal locking
- Bumper castors on 4 corners of the bed
- Auto-counter function Auto-counter to provide the patient from sliding onto the foot end
Technical parameter
| Model | YA-D3-3 |
| Size（L*W*H） | 2130*970*500mm (83.8″ x 38.1″ x 19.6″) |
| Lying surface: | 1880*830mm (74″ x 32.6″ ) |
| High-Low: | 500-750mm (9.6″ – 29.5″ ) |
| Back section adjustable | 0° to 75° |
| Knee section adjustable | 0° to 40° |
| Safe working load | 175kg（385 Ibs） |
Standard Accessories
- Head/Foot Board 2 pieces
- Side Rails 2 pieces
- Bed Frame 1 set
- Bed Boards 4 pieces
- Casters 4 pieces
- IV Pole Holder 4 pieces
- IV Pole 1 piece
- Drainage Bag Holders 2 pieces
